TBF20-29PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
20-29 MIL-DTL-5015CA Non-RoHS Compliant GENERAL PURPOSE Circular Connector Standard -55C~125C
PDF
/
Inventory: 1832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material COPPER ALLOY
Mounting Type Panel Mount
Mounting Feature Flange
Housing Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
Pbfree Code no
Part Status Active
Fastening Type Threaded
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 17
Shielding Unshielded
Contact Gender MALE-FEMALE
Housing Color Olive
Empty Shell NO
Body/Shell Style RECEPTACLE
Connector Style Standard
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 17
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 20-29
Orientation (Convert To) N (Normal)
Compliance
RoHS Status Non-RoHS Compliant
