TBF20-15PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
20-15 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 41A 500V
PDF
/
Buying Options
Total Price: USD $177.6
Unit Price: USD $177.6016
≥1 USD $177.6016
≥10 USD $153.92168
Inventory: 65
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material COPPER ALLOY
Mount Panel
Mounting Type Panel Mount
Mounting Feature Flange
Housing Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2007
Series MIL-DTL-5015, CA
Pbfree Code no
Part Status Active
Gender Female
Fastening Type Threaded
Voltage - Rated DC 700V
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 7
Shielding Unshielded
Current Rating 41A
Voltage - Rated AC 500V
Housing Color Olive
Empty Shell NO
Body/Shell Style RECEPTACLE
Connector Style Standard
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 7
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 20-15
Orientation (Convert To) N (Normal)
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
