TBF20-14PSB
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
Circular Adapter Connector
PDF
/
Inventory: 4801
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
Technical
Shell Size - Insert (Convert To) 20-14
Number of Positions (Convert To) 5
Orientation (Convert To) N (Normal)
Shell Size - Insert (Convert From) 20-14
Orientation (Convert From) N (Normal)
Number of Positions (Convert From) 5
Housing Finish Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Includes 2 pcs - 1 Adapter, 1 O-Ring
Connector Style Standard
Housing Color Olive
Voltage - Rated AC 500V
Current Rating 74A
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Unshielded
Voltage - Rated DC 700V
Fastening Type Reverse Bayonet Lock
Connector Type Standard
Part Status Active
Series MIL-DTL-5015, CA
Published 2015
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Aluminum Alloy
Number of Pins 8
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
