TBF18-5PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
18-5 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 41A 900V
PDF
/
Inventory: 3034
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Panel
Mounting Type Panel Mount
Mounting Feature Flange
Number of Pins 12
Housing Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
JESD-609 Code e4
Pbfree Code no
Part Status Active
Fastening Type Threaded
Voltage - Rated DC 1.25kV
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Shielding Unshielded
Current Rating 41A
Voltage - Rated AC 900V
Contact Gender MALE-FEMALE
Housing Color Olive
Empty Shell NO
Body/Shell Style RECEPTACLE
Connector Style Standard
Contact Finish Termination GOLD
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 3
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 18-5
Orientation (Convert To) N (Normal)
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
