TBF16S-1PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
16S-1 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 22A 500V
PDF
/
Inventory: 6353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material COPPER ALLOY
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Housing Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series MIL-DTL-5015, CA
Pbfree Code no
Part Status Active
Termination Crimp
Fastening Type Threaded
Voltage - Rated DC 700V
Contact Finish - Mating GOLD
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 7
Orientation Straight
Shielding Unshielded
Current Rating 22A
Voltage - Rated AC 500V
Contact Gender MALE-FEMALE
Housing Color Olive
Empty Shell NO
Body/Shell Style RECEPTACLE
Connector Style Standard
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 7
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 16S-1
Orientation (Convert To) N (Normal)
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
