TBF16-11PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
16-11 MIL-DTL-5015CA Non-RoHS Compliant Dust Tight IP65Water Resistant Circular Connector Standard -55C~125C 41A 500V
PDF
/
Buying Options
Total Price: USD $152.78
Unit Price: USD $152.77623
≥1 USD $152.77623
≥10 USD $144.128515
≥100 USD $135.970295
≥500 USD $128.273866
≥1000 USD $121.013078
Inventory: 1597
Minimum: 1
-
+
Technical Details
Technical
Orientation (Convert From) N (Normal)
Shell Size - Insert (Convert From) 16-11
Orientation (Convert To) N (Normal)
Number of Positions (Convert From) 2
Housing Finish Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Connector Style Standard
Body/Shell Style RECEPTACLE
Empty Shell NO
Housing Color Olive
Contact Gender MALE-FEMALE
Voltage - Rated AC 500V
Current Rating 41A
Shielding Unshielded
Total Number of Contacts 2
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating GOLD
Voltage - Rated DC 700V
Fastening Type Threaded
Part Status Active
Pbfree Code no
Series MIL-DTL-5015, CA
Packaging Bulk
Operating Temperature -55°C~125°C
Compliance
RoHS Status Non-RoHS Compliant
Ratings Dust Tight, IP65, Water Resistant
Physical
Housing Material Aluminum Alloy
Number of Pins 12
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
Contact Material COPPER ALLOY
