KPTB22-55PSW
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
22-55 KPT Non-RoHS Compliant 2014 Circular Connector Standard -55C~125C 7.5A 600V 40.08mm
PDF
/
Inventory: 9031
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount
Mounting Feature Flange
Housing Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series KPT
Part Status Active
Termination Solder
Connector Type Circular, Standard
Gender Receptacle
Fastening Type Bayonet Lock
Voltage - Rated DC 850V
Orientation Straight
Shielding Unshielded
Depth 40.08mm
Current Rating 7.5A
Voltage - Rated AC 600V
Housing Color Olive
Max Current Rating 7.5A
Plating Cadmium, Chromate
Connector Style Standard
Body Plating Cadmium
Convert From (Adapter End) Female Sockets
Convert To (Adapter End) Male Pins
Housing Finish Chromate
Number of Positions (Convert From) 55
Orientation (Convert From) W
Shell Size - Insert (Convert From) 22-55
Dimensions
Length 35.71mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
