KPTB14-19PS
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
Conn Miniature Circular PIN/SKT 19 POS Solder ST Panel Mount 19 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $173.82
Unit Price: USD $173.822207
≥1 USD $173.822207
≥10 USD $163.983217
≥100 USD $154.701143
≥500 USD $145.944476
≥1000 USD $137.683473
Inventory: 4480
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 28.6mm
Technical
Orientation (Convert To) N (Normal)
Shell Size - Insert (Convert From) 14-19
Orientation (Convert From) N (Normal)
Number of Positions (Convert From) 19
Housing Finish Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Connector Style Standard
Plating Cadmium, Chromate
Max Current Rating 7.5A
Housing Color Olive
Voltage - Rated AC 600V
Current Rating 7.5A
Depth 29mm
Shielding Unshielded
Orientation Straight
Voltage - Rated DC 850V
Fastening Type Bayonet Lock
Termination Solder
Part Status Active
Series KPT
Published 2000
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Supply Chain
Factory Lead Time 12 Weeks
