PTB22-21PSZ
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Adapters
Description
AMPHENOL PTB22-21PSZ Circular Connector, PT Series, MIL-DTL-26482 Series I Equivalent, Thru Bulkhead Receptacle, 21
PDF
/
Inventory: 4657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Shell Size - Insert (Convert From) 22-21
Orientation (Convert From) Z
Number of Positions (Convert From) 21
Housing Finish Olive Drab Chromate
Convert To (Adapter End) Male Pins
Convert From (Adapter End) Female Sockets
Body Plating Cadmium
Connector Style Standard
Empty Shell NO
Housing Color Olive
Shielding Unshielded
Orientation Straight
Total Number of Contacts 21
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Fastening Type Bayonet Lock
Gender Receptacle
Connector Type Circular
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-26482 Series I, PT
Published 2006
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Housing Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
