42296
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors - Accessories
Description
CONN COVER 22-96 BLACK
PDF
/
Inventory: 6957
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN
Total Number of Contacts 29
Terminal Pitch 2.0066mm
Number of Conductors ONE
Reference Standard UL
Shell Size - Insert 22-96
Reliability COMMERCIAL
Body Length or Diameter 2.295 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.079 inch
Contact Gender FEMALE
Operating Temperature (Min) -40°C
Body Depth 0.368 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.079 inch
Termination Type WIRE WRAP
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Durability 50 Cycles
Accessory Type Cap (Cover)
Contact Finish Termination TIN
Contact Pattern RECTANGULAR
Insertion Force-Max 2.9468 N
Withdrawl Force-Min .1946 N
Color Black
Connector Type BOARD CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Metal Chain with Ring
Series MIL-E-QUAL?
Dimensions
Length - Termination 0.482 inch
Physical
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Material Nylon
Mounting Type BOARD
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status ROHS3 Compliant
