1582175
RoHS
/
Package /
Category Cable Assemblies / Circular Cable Assemblies
Description
Phoenix Contact QPD Series, Panel Mount IDC Connector, 4 Way
PDF
/
Inventory: 1423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Panel
Housing Material Polyamide
Weight 89.000011g
1st Connector Mounting Type Panel Feed Through
Technical
Published 2011
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDT
Connector Type Circular, Wire Leads
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color Multiple
Voltage - Rated 630V
Orientation Straight
Shielding Unshielded
Ingress Protection IP66/68/69K - Dust Tight, Water Resistant, Waterproof
Current Rating 20A
Number of Contacts 4
Cable Type Individual
Usage Industrial Environments
1st Connector Number of Positions Loaded All
1st Connector Number of Positions 4 (3 + PE)
Assembly Configuration Standard
2nd Connector Type Wire Leads
1st Connector Shell Size - Insert M25
Dimensions
Length 1.64' 500.00mm
Compliance
RoHS Status RoHS Compliant
Ratings IP66
