MN47A4AC01M100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / Circular Cable Assemblies
Description
Cable Assembly Coaxial 10m 16AWG Circular to Circular 4 to 4 POS M-F
PDF
/
Buying Options
Total Price: USD $91.74
Unit Price: USD $91.737832
≥1 USD $91.737832
≥10 USD $86.545124
≥100 USD $81.646339
≥500 USD $77.024846
≥1000 USD $72.664953
Inventory: 1567
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 32.8' 10.00m
Technical
2nd Connector Shell Size - Insert 7/8 M22
2nd Connector Orientation Keyed
2nd Connector Number of Positions Loaded All
2nd Connector Number of Positions 4
2nd Connector Gender Female Sockets
1st Connector Shell Size - Insert 7/8 M22
Connector Type B Circular
1st Connector Orientation Keyed
2nd Connector Type Plug
Assembly Configuration Standard
1st Connector Number of Positions 4
Connector Type A Circular
1st Connector Type Receptacle
1st Connector Number of Positions Loaded All
1st Connector Gender Male Pins
Usage Industrial Environments
Wire/Cable Gauge 16 AWG
Cable Length 10m
Wire/Cable Type Coaxial
Cable Type Round
Max Current Rating 10A
Max Voltage Rating (AC) 600V
Ingress Protection IP67 - Dust Tight, Waterproof
Shielding Unshielded
Color Yellow
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Connector Type Circular
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series miniBOSS? M22
Published 2009
Physical
2nd Connector Mounting Type Free Hanging (In-Line)
Cable Material Polyvinyl Chloride (PVC)
1st Connector Mounting Type Free Hanging (In-Line)
Number of Pins 4
Contact Plating Gold
Supply Chain
Factory Lead Time 12 Weeks
