9124393500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
CIR BRKR THRMMAG 7A 250VAC 80VDC
PDF
/
Inventory: 2229
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Terminal Shape SNAP ON
Technical
Published 2009
Series CB4200
Part Status Active
Voltage - Rated DC 80V
Current Rating 7A
Reference Standard CSA; UL; VDE
Voltage - Rated AC 250V
Approval Agency CSA C22.2 No 235, UL1077, VDE
Body Length or Diameter 80mm
Operating Temperature (Max) 55°C
Actuator Type Push to Reset
Operating Temperature (Min) -30°C
Environmental Characteristics CORROSSION RESISTANT; MOISTURE RESISTANT
Number of Poles 2
Breaker Type Thermal Magnetic
Rated Breaking Capacity 1000 A
Circuit Function TRIP
Dimensions
Body Height 53mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
