4430.2296
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
Circuit Breakers TA45 ORANGE RCKR 2 A
PDF
/
Buying Options
Total Price: USD $23.62
Unit Price: USD $23.6192
≥1 USD $23.6192
≥10 USD $17.48296
≥100 USD $17.38
Inventory: 103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Snap in
Mounting Type Panel Mount
Weight 32.700013g
Technical
Series TA45
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Quick Connect
Max Operating Temperature 55°C
Min Operating Temperature -10°C
Color White
Voltage - Rated 240V
Voltage - Rated DC 60V
Current Rating (Amps) 2A
Current Rating 2A
Voltage - Rated AC 240V
Approval Agency CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077
Actuator Type Pushbutton
Number of Poles 2
Breaker Type Thermal
Dimensions
Height 34mm
Length 48mm
Width 25mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
