2800895
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
CIR BRKR THRMMAG 5A 277VAC 80VDC
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 24.6mm
Length 52mm
Height 45mm
Technical
Breaker Type Thermal Magnetic
Number of Poles 2
Actuator Type Slide Switch
Approval Agency CSA, KC, UL, VDE
Voltage - Rated AC 277V
Current Rating 5A
Reach Compliance Code not_compliant
Voltage - Rated DC 80V
Color Grey
Min Operating Temperature -30°C
Max Operating Temperature 60°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CB
Published 2013
Physical
Mounting Type Holder
Mount Panel
Supply Chain
Factory Lead Time 8 Weeks
