0903029
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
Circuit Breakers EC-E1 8A 8 A, N/O SIGNAL CNT
PDF
/
Buying Options
Total Price: USD $92
Unit Price: USD $91.9952
≥1 USD $91.9952
≥10 USD $89.12376
≥100 USD $79.86
Inventory: 61
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount DIN Rail
Mounting Type DIN Rail
Technical
Series CLIPLINE
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Max Operating Temperature 50°C
Min Operating Temperature 0°C
Color Black
Voltage - Rated DC 24V
Depth 80mm
Reach Compliance Code unknown
Current Rating 8A
Approval Agency CSA, UL
Actuator Type Slide Switch
Number of Poles 1
Breaker Type Solid State
Circuit Protection Type MAGNETIC CIRCUIT BREAKER
Stripping Length 10mm
Trip Current 8A
Dimensions
Height 80mm
Length 83mm
Width 12.5mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
