0903026
RoHS
RoHS compliant
RoHS compliantPackage /
Category Circuit Protection / Circuit Breakers
Description
Circuit Breakers EC-E1 4A 4 A, N/O SIGNAL CNT
PDF
/
Buying Options
Total Price: USD $92
Unit Price: USD $91.9952
≥1 USD $91.9952
≥10 USD $89.12376
≥100 USD $79.86
Inventory: 73
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 12.5mm
Length 83mm
Height 83mm
Technical
Trip Current 4A
Stripping Length 10mm
Circuit Protection Type MAGNETIC CIRCUIT BREAKER
Breaker Type Solid State
Number of Poles 1
Actuator Type Slide Switch
Approval Agency CSA, UL
Current Rating 4A
Reach Compliance Code unknown
Depth 80mm
Voltage - Rated DC 24V
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 50°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CLIPLINE
Physical
Weight 75.020011g
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 4 Weeks
