RT0603BRD07300KL
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0603 (1608Metric) FIXED RESISTOR RT 0.063Lx0.031W 1.60mmx0.80mm 0.1W 1/10W 300kOhm ±25ppm/C
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.1232
≥1 USD $0.1232
≥10 USD $0.09152
≥100 USD $0.072336
≥500 USD $0.064856
≥1000 USD $0.049386
≥3000 USD $0.043639
Inventory: 1333
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.022 0.55mm
Height 550μm
Technical
Case Code (Imperial) 0603
Rated Power Dissipation (P) 0.1W
Case Code (Metric) 1608
Military Standard Not
Resistor Type FIXED RESISTOR
Construction RECTANGULAR PACKAGE
Depth 800μm
Max Power Dissipation 100mW
Packing Method TR, Paper, 7 Inch
Voltage - Rated DC 50V
Power Rating 100mW
Additional Feature HIGH PRECISION
Voltage - Rated 75V
Power (Watts) 0.1W 1/10W
Composition Thin Film
Resistance 300kOhm
Temperature Coefficient ±25ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Moisture Resistant
JESD-609 Code e3
Tolerance ±0.1%
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Series RT
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Weight 2.012816mg
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0603 (1608 Metric)
Contact Plating Tin
Supply Chain
Factory Lead Time 24 Weeks
