1623486-1
RoHS
/
Package 1206
Category Resistors / Chip Resistor - Surface Mount
Description
FIXED RESISTOR 1206 Chip Resistor 1% 200ppm/C 30Ohm
PDF
/
Inventory: 6119
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.5494mm
Length 3.0988mm
Height 660.4μm
Technical
Power Dissipation-Max 250mW
Military Standard Not
Resistor Type FIXED RESISTOR
Depth 1.55mm
Packing Method TR
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 30Ohm
Temperature Coefficient 200 ppm/°C
Number of Terminations 2
Pbfree Code yes
Tolerance 1%
Published 2010
Packaging Tape & Reel (TR)
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1206
