RP2012T-R56-J
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
RES 0.56 OHM 5% 1/3W 0805
PDF
/
Inventory: 5214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.020 0.50mm
Height 400μm
Technical
Case Code (Imperial) 0805
Case Code (Metric) 2012
Voltage - Rated DC 100V
Power Rating 333mW
Power (Watts) 0.333W 1/3W
Composition Metal Film
Resistance 560mOhm
Temperature Coefficient 0/ +350ppm/°C
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±5%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series RP
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 0805 (2012 Metric)
