TRR10EZPJ133
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
TRR FIXED RESISTOR 0805 (2012Metric) Chip Resistor ±5% ±200ppm/C 13kOhm 0.125W 1/8W
PDF
/
Inventory: 3675
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 0805 (2012 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Published 2014
Series TRR
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±5%
JESD-609 Code e3
Feature Anti-Sulfur
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±200ppm/°C
Resistance 13kOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 0.125W 1/8W
Subcategory FIXED RESISTOR
Packing Method TR, PAPER, 7 INCH
Construction Chip
Resistor Type FIXED RESISTOR
Reference Standard TS 16949
Working Voltage 150V
Dimensions
Height Seated (Max) 0.026 0.65mm
Compliance
RoHS Status ROHS3 Compliant
