MCR10EZHF3921
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0805 (2012Metric) FIXED RESISTOR MCR 0.079Lx0.049W 2.00mmx1.25mm 0.125W 1/8W 3.92kOhm ±100ppm/C
PDF
/
Inventory: 9662
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.026 0.65mm
Height 609.6μm
Technical
Case Code (Imperial) 0805
Case Code (Metric) 2012
Resistor Type FIXED RESISTOR
Construction Chip
Max Power Dissipation 125mW
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 150V
Power Rating 125mW
Subcategory Fixed Resistors
Power (Watts) 0.125W 1/8W
Composition Thick Film
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Resistance 3.92kOhm
Temperature Coefficient ±100ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series MCR
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Terminal Shape WRAPAROUND
Package / Case 0805 (2012 Metric)
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
