MCR10EZHF1214
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0805 (2012Metric) FIXED RESISTOR MCR 0.079Lx0.049W 2.00mmx1.25mm 0.125W 1/8W 1.21MOhm ±100ppm/C
PDF
/
Inventory: 7160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 0805 (2012 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Published 2002
Series MCR
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±1%
JESD-609 Code e3
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 1.21MOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 0.125W 1/8W
Subcategory Fixed Resistors
Voltage - Rated DC 150V
Packing Method TR, PAPER, 7 INCH
Max Power Dissipation 125mW
Construction Chip
Resistor Type FIXED RESISTOR
Case Code (Metric) 2012
Case Code (Imperial) 0805
Dimensions
Height 609.6μm
Height Seated (Max) 0.026 0.65mm
Compliance
RoHS Status ROHS3 Compliant
