MCR100JZHJLR12
RoHS
RoHS compliant
RoHS compliantPackage 2512 (6432 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
2512 (6432Metric) FIXED RESISTOR MCR 0.248Lx0.126W 6.30mmx3.20mm 1W 120mOhm 200/ +600ppm/C
PDF
/
Inventory: 1350
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 2512 (6432 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2015
Series MCR
Size / Dimension 0.248Lx0.126W 6.30mmx3.20mm
Tolerance ±5%
JESD-609 Code e3
Feature Automotive AEC-Q200
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient 200/ +600ppm/°C
Resistance 120mOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 1W
Subcategory FIXED RESISTOR
Packing Method TR, EMBOSSED, 7 INCH
Construction Chip
Resistor Type FIXED RESISTOR
Reference Standard TS 16949
Rated Power Dissipation (P) 1W
Working Voltage 3.01V
Dimensions
Height Seated (Max) 0.028 0.70mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
