MCR03EZPJ4R7
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0603 (1608Metric) FIXED RESISTOR MCR 0.063Lx0.031W 1.60mmx0.80mm 0.1W 1/10W 4.7Ohm ±400ppm/C
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.11115
≥1 USD $0.11115
≥10 USD $0.0912
≥100 USD $0.08835
≥500 USD $0.0855
≥1000 USD $0.08265
≥10000 USD $0.0741
Inventory: 1185
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case 0603 (1608 Metric)
Terminal Shape WRAPAROUND
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Published 2012
Series MCR
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Tolerance ±5%
JESD-609 Code e3
Feature Automotive AEC-Q200
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±400ppm/°C
Resistance 4.7Ohm
Composition Thick Film
Power (Watts) 0.1W 1/10W
Power Rating 100mW
Voltage - Rated DC 50V
Packing Method TR, PAPER, 7 INCH
Max Power Dissipation 100mW
Construction Rectangular
Resistor Type FIXED RESISTOR
Reference Standard TS 16949
Case Code (Metric) 1608
Rated Power Dissipation (P) 0.1W
Case Code (Imperial) 0603
Dimensions
Height 558.8μm
Height Seated (Max) 0.022 0.55mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
