MCR006YRTJ160
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0201 (0603Metric) FIXED RESISTOR MCR 0.024Lx0.012W 0.60mmx0.30mm 0.05W 1/20W 16Ohm ±250ppm/C
PDF
/
Inventory: 2788
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.010 0.26mm
Height 254μm
Technical
Case Code (Imperial) 0201
Rated Power Dissipation (P) 0.05W
Case Code (Metric) 0603
Reference Standard TS 16949
Resistor Type FIXED RESISTOR
Construction Chip
Max Power Dissipation 50mW
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 25V
Power Rating 50mW
Subcategory FIXED RESISTOR
Power (Watts) 0.05W 1/20W
Composition Thick Film
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Resistance 16Ohm
Temperature Coefficient ±250ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e3
Tolerance ±5%
Size / Dimension 0.024Lx0.012W 0.60mmx0.30mm
Series MCR
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0201 (0603 Metric)
