S3-15RF1
RoHS
RoHS compliant
RoHS compliantPackage 6327 J-Lead
Category Resistors / Chip Resistor - Surface Mount
Description
S 6327J-Lead Chip Resistor ±1% ±20ppm/C 15Ohms 3W
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
≥10 USD $1.52416
≥100 USD $1.48896
≥500 USD $1.401488
≥1000 USD $1.16204
≥3000 USD $1.051107
Inventory: 334
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6.9088mm
Length 15.9004mm
Height Seated (Max) 0.268 6.80mm
Height 6.8072mm
Technical
Max Power Dissipation 3W
Power (Watts) 3W
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 275°C
Resistance 15Ohms
Temperature Coefficient ±20ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Current Sense, Flame Proof, Moisture Resistant, Pulse Withstanding, Safety
Tolerance ±1%
Size / Dimension 0.626Lx0.272W 15.90mmx6.90mm
Series S
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~275°C
Physical
Package / Case 6327 J-Lead
Supply Chain
Factory Lead Time 8 Weeks
