ERJB2AF470V
RoHS
/
Package 1206
Category Resistors / Chip Resistor - Surface Mount
Description
FIXED RESISTOR 1206 Chip Resistor 1% 100ppm/C 47Ohm 500mW
PDF
/
Inventory: 2174
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.2mm
Length 3.2mm
Height 650μm
Technical
Rated Temperature 70°C
Rated Power Dissipation (P) 0.75W
Military Standard Not
Resistor Type FIXED RESISTOR
Construction Rectangular
Depth 1.6mm
Packing Method TR, PUNCHED, 7 INCH
Voltage - Rated DC 200V
Power Rating 500mW
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 155°C
Resistance 47Ohm
Temperature Coefficient 100 ppm/°C
Number of Terminations 2
JESD-609 Code e3
Tolerance 1%
Published 2008
Packaging Cut Tape
Physical
Number of Pins 2
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1206
Contact Plating Tin
Supply Chain
Factory Lead Time 11 Weeks
