ERJB2AF332V
RoHS
/
Package 1206
Category Resistors / Chip Resistor - Surface Mount
Description
FIXED RESISTOR 1206 Chip Resistor 1% 100ppm/C 3.3kOhm 500mW
PDF
/
Inventory: 8326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Tin
Package / Case 1206
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Number of Pins 2
Technical
Packaging Cut Tape
Published 2008
Tolerance 1%
JESD-609 Code e3
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient 100 ppm/°C
Resistance 3.3kOhm
Max Operating Temperature 155°C
Min Operating Temperature -55°C
Composition Thick Film
Power Rating 500mW
Voltage - Rated DC 200V
Packing Method TR, PUNCHED, 7 INCH
Depth 1.6mm
Construction Rectangular
Resistor Type FIXED RESISTOR
Rated Power Dissipation (P) 0.75W
Rated Temperature 70°C
Dimensions
Height 650μm
Length 3.2mm
Width 3.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
