ERJB1AF360U
RoHS
/
Package 2010
Category Resistors / Chip Resistor - Surface Mount
Description
2010 FIXED RESISTOR Chip Resistor 1W 36Ohm 100ppm/C 1%
PDF
/
Inventory: 4222
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 5mm
Height 550μm
Technical
Network Type ISOLATED
Rated Temperature 70°C
Size Code 1020
Number of Elements 3
Rated Power Dissipation (P) 1W
Reference Standard AEC-Q200
Resistor Type FIXED RESISTOR
Construction Rectangular
Depth 2.5mm
Number of Functions 1
Packing Method TR, Embossed, 7 Inch
Voltage - Rated DC 200V
Power Rating 1W
HTS Code 8533.21.00.20
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 155°C
Terminal Finish Tin (Sn)
Resistance 36Ohm
Temperature Coefficient 100 ppm/°C
ECCN Code EAR99
Termination Flat
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 1%
Published 2010
Packaging Cut Tape
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 2010
