TDH35P7R50JE
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Resistors / Chip Resistor - Surface Mount
Description
TDH35 FIXED RESISTOR TO-263-3D2Pak (2Leads + Tab) TO-263AB Chip Resistor ±5% ±100ppm/C 7.5Ohm 35W
PDF
/
Buying Options
Total Price: USD $7.94
Unit Price: USD $7.9376
≥1 USD $7.9376
≥10 USD $7.0752
≥100 USD $6.9432
≥500 USD $6.11673
≥1000 USD $5.02561
≥3000 USD $4.794178
Inventory: 40
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height Seated (Max) 0.185 4.70mm
Height 4.4958mm
Technical
Size Code 4034
Resistor Type FIXED RESISTOR
Construction RECTANGULAR PACKAGE
Depth 4.5mm
Terminal Pitch 5.08mm
Max Power Dissipation 35W
Voltage - Rated DC 350V
Power Rating 35W
Additional Feature RATED POWER DISSIPATED USING HEAT SINK: 35W
Voltage - Rated 350V
Composition Thick Film
Terminal Finish Tin/Silver (Sn/Ag)
Resistance 7.5Ohm
Temperature Coefficient ±100ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Moisture Resistant
JESD-609 Code e2
Tolerance ±5%
Size / Dimension 0.398Lx0.378W 10.10mmx9.60mm
Series TDH35
Published 2011
Packaging Bulk
Operating Temperature -55°C~150°C
Physical
Terminal Shape GULL WING
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
