NRC10J152TR10F
RoHS
/
Package 0805
Category Resistors / Chip Resistor - Surface Mount
Description
FIXED RESISTOR 0805 Chip Resistor 5% 200ppm/C 1.5kOhm 125mW
PDF
/
Inventory: 7942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Package / Case 0805
Technical
Tolerance 5%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient 200 ppm/°C
Resistance 1.5kOhm
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Composition Thick Film
HTS Code 8533.21.00.30
Subcategory FIXED RESISTOR
Power Rating 125mW
Voltage - Rated DC 150V
Packing Method TR, 10 Inch
Depth 1.25mm
Construction Chip
Resistor Type FIXED RESISTOR
Military Standard Not
Rated Power Dissipation (P) 0.125W
Dimensions
Length 2mm
Compliance
RoHS Status RoHS Compliant
