SR731JTTDR511F
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0603 (1608Metric) FIXED RESISTOR SR73 0.063Lx0.031W 1.60mmx0.80mm 0.25W 1/4W 511mOhm ±200ppm/C
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
≥10 USD $0.32032
≥100 USD $0.256608
≥500 USD $0.190608
≥1000 USD $0.134464
≥3000 USD $0.11975
Inventory: 160
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.022 0.55mm
Height 450μm
Technical
Case Code (Imperial) 0603
Case Code (Metric) 1608
Resistor Type FIXED RESISTOR
Construction Rectangular
Packing Method TR, PUNCHED PAPER, 7 INCH
Power Rating 200mW
Voltage - Rated 1.41V
Power (Watts) 0.25W 1/4W
Composition Thick Film
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 511mOhm
Temperature Coefficient ±200ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automotive AEC-Q200, Current Sense
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Series SR73
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0603 (1608 Metric)
Supply Chain
Factory Lead Time 8 Weeks
