RN73H1ETTP6801B25
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0402 (1005Metric) FIXED RESISTOR RN73H 0.039Lx0.020W 1.00mmx0.50mm 0.063W 1/16W 6.8kOhm ±25ppm/C
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.23056
≥100 USD $0.17864
≥500 USD $0.15884
≥1000 USD $0.119152
≥3000 USD $0.104685
Inventory: 5416
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.016 0.40mm
Height 350μm
Technical
Case Code (Imperial) 0402
Rated Power Dissipation (P) 0.063W
Case Code (Metric) 1005
Resistor Type FIXED RESISTOR
Construction Rectangular
Packing Method TR, PUNCHED PAPER, 7 INCH
Voltage - Rated DC 50V
Power Rating 63mW
Voltage - Rated 50V
Power (Watts) 0.063W 1/16W
Composition Metal Film
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 6.8kOhm
Temperature Coefficient ±25ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automotive AEC-Q200, Moisture Resistant
JESD-609 Code e3
Tolerance ±0.1%
Size / Dimension 0.039Lx0.020W 1.00mmx0.50mm
Series RN73H
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Weight 652.039032μg
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0402 (1005 Metric)
Supply Chain
Factory Lead Time 10 Weeks
