RK73H2ATTD1503D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0805 (2012Metric) FIXED RESISTOR RK73H 0.079Lx0.049W 2.00mmx1.25mm 0.25W 1/4W 150kOhm ±100ppm/C
PDF
/
Inventory: 8159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 0805 (2012 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Weight 5.499807mg
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Series RK73H
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±0.5%
JESD-609 Code e3
Feature Automotive AEC-Q200, Moisture Resistant
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient ±100ppm/°C
Resistance 150kOhm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 0.25W 1/4W
Voltage - Rated 150V
Power Rating 125mW
Packing Method TR, Punched Paper, 7 Inch
Construction Rectangular
Resistor Type FIXED RESISTOR
Case Code (Metric) 2012
Case Code (Imperial) 0805
Dimensions
Height 500μm
Height Seated (Max) 0.024 0.60mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
