PSEDTEL50J
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Resistors / Chip Resistor - Surface Mount
Description
Nonstandard FIXED RESISTOR PSE 0.252Lx0.252W 6.40mmx6.40mm 5W 500muOhm ±150ppm/C
PDF
/
Inventory: 4280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Nonstandard
Surface Mount YES
Terminal Shape ONE SURFACE
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -65°C~155°C
Packaging Tape & Reel (TR)
Series PSE
Size / Dimension 0.252Lx0.252W 6.40mmx6.40mm
Tolerance ±5%
JESD-609 Code e1
Feature Automotive AEC-Q200, Current Sense, Moisture Resistant
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient ±150ppm/°C
Resistance 500μOhm
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Composition Metal Element
Subcategory FIXED RESISTOR
Power Rating 5W
Packing Method TR, EMBOSSED
Technology METAL ALLOY
Construction Rectangular
Resistor Type FIXED RESISTOR
Case Code (Metric) 6464
Rated Power Dissipation (P) 5W
Case Code (Imperial) 2525
Dimensions
Height 650μm
Height Seated (Max) 0.035 0.90mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
