MP725-200-1%
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Resistors / Chip Resistor - Surface Mount
Description
MP725 FIXED RESISTOR TO-263-3D2Pak (2Leads + Tab) TO-263AB Chip Resistor ±1% -20/ +80ppm/C 200Ohm 25W
PDF
/
Buying Options
Total Price: USD $7.86
Unit Price: USD $7.8584
≥1 USD $7.8584
≥10 USD $5.22192
≥100 USD $4.172432
≥500 USD $3.814008
Inventory: 2135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Terminal Shape GULL WING
Technical
Operating Temperature -55°C~150°C
Packaging Cut Tape (CT)
Published 2004
Series MP725
Size / Dimension 0.325Lx0.320W 8.26mmx8.13mm
Tolerance ±1%
JESD-609 Code e3
Feature Current Sense, Moisture Resistant, Non-Inductive
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient -20/ +80ppm/°C
Resistance 200Ohm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Voltage - Rated 200V
Subcategory FIXED RESISTOR
Power Rating 25W
Voltage - Rated DC 200V
Packing Method TR
Max Power Dissipation 25W
Depth 2.79mm
Construction Rectangular
Resistor Type FIXED RESISTOR
Lead Length 4.06mm
Insulation Resistance 10GOhm
Power Dissipation 2.5W
Dimensions
Height 3.048mm
Height Seated (Max) 0.120 3.05mm
Thickness 2.79mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
