MP725-20.0-1%
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Resistors / Chip Resistor - Surface Mount
Description
MP725 FIXED RESISTOR TO-263-3D2Pak (2Leads + Tab) TO-263AB Chip Resistor ±1% -20/ +80ppm/C 20Ohm 25W
PDF
/
Buying Options
Total Price: USD $7.86
Unit Price: USD $7.8584
≥1 USD $7.8584
≥10 USD $5.22192
≥100 USD $4.172432
≥500 USD $3.814008
Inventory: 1905
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.120 3.05mm
Technical
Resistor Type FIXED RESISTOR
Construction Rectangular
Packing Method TR
Voltage - Rated DC 200V
Power Rating 25W
Subcategory FIXED RESISTOR
Composition Thick Film
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 20Ohm
Temperature Coefficient -20/ +80ppm/°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Current Sense, Moisture Resistant, Non-Inductive
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.325Lx0.320W 8.26mmx8.13mm
Series MP725
Packaging Cut Tape (CT)
Operating Temperature -55°C~150°C
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape GULL WING
Surface Mount YES
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Supply Chain
Factory Lead Time 9 Weeks
