AHA80AJB-27R
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
RES CHAS MNT 27 OHM 5% 80W
PDF
/
Inventory: 6493
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.024 26.00mm
Height 26.0096mm
Technical
Coating, Housing Type Aluminum
Lead/Base Style Solder
Lead Style Threaded
Working Voltage 2000V
Lead Length 18mm
Resistor Type FIXED RESISTOR
Technology WIRE WOUND
Max Power Dissipation 80W
Subcategory Fixed Resistors
HTS Code 8533.21.00.80
Composition Wirewound
Resistance 27Ohm
Temperature Coefficient ±200ppm/°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 2.598Lx1.850W 66.00mmx47.00mm
Series AHA
Published 2014
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Housing Material Aluminium
Mounting Feature Flanges
Package / Case Axial, Box
Supply Chain
Factory Lead Time 25 Weeks
