AHA10BFB-10R
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
RES CHAS MNT 10 OHM 1% 100W
PDF
/
Inventory: 3187
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Package / Case Axial, Box
Mounting Feature Flanges
Housing Material Aluminium
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Published 2010
Series AHA
Size / Dimension 3.504Lx2.756W 89.00mmx70.00mm
Tolerance ±1%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±200ppm/°C
Resistance 10Ohm
Composition Wirewound
HTS Code 8533.21.00.80
Subcategory Fixed Resistors
Max Power Dissipation 100W
Technology WIRE WOUND
Resistor Type FIXED RESISTOR
Lead Length 23mm
Working Voltage 4500V
Lead Style M4 Threaded
Lead/Base Style Solder
Coating, Housing Type Aluminum
Dimensions
Height 45.4914mm
Height Seated (Max) 1.795 45.60mm
Compliance
RoHS Status ROHS3 Compliant
