RER75F10R5PC02
RoHS
/
Package Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Military MIL-PRF-39009RER75 Axial Box Chassis Mount Resistor ±1% ±50ppm/C 10.5Ohms 30W
PDF
/
Inventory: 7741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 28.956mm
Length 49.9872mm
Height Seated (Max) 0.625 15.87mm
Height 15.875mm
Technical
Coating, Housing Type Aluminum
Lead/Base Style Solder
Lead Style Solder Lugs
Failure Rate P (0.1%)
Max Power Dissipation 30W
Power Rating 30W
Power (Watts) 30W
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 250°C
Resistance 10.5Ohms
Temperature Coefficient ±50ppm/°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Military, Moisture Resistant
Tolerance ±1%
Size / Dimension 1.968Lx1.140W 49.99mmx28.96mm
Series Military, MIL-PRF-39009, RER75
Published 2013
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Weight 28g
Housing Material Aluminium
Mounting Feature Flanges
Package / Case Axial, Box
Supply Chain
Factory Lead Time 7 Weeks
