RER70F8251PC02
RoHS
/
Package Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Military MIL-PRF-39009RER70 Axial Box Chassis Mount Resistor ±1% ±20ppm/C 8.25kOhms 20W
PDF
/
Inventory: 6693
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Package / Case Axial, Box
Mounting Feature Flanges
Housing Material Aluminium
Weight 13g
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Published 2013
Series Military, MIL-PRF-39009, RER70
Size / Dimension 1.062Lx1.080W 26.97mmx27.43mm
Tolerance ±1%
Feature Military, Moisture Resistant
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient ±20ppm/°C
Resistance 8.25kOhms
Max Operating Temperature 250°C
Min Operating Temperature -55°C
Composition Wirewound
Power (Watts) 20W
Power Rating 20W
Max Power Dissipation 20W
Failure Rate P (0.1%)
Lead Style Solder Lugs
Lead/Base Style Solder
Coating, Housing Type Aluminum
Dimensions
Height 14.2494mm
Height Seated (Max) 0.561 14.25mm
Length 26.9748mm
Width 27.432mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
