RER45F9R09RC02
RoHS
/
Package Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Military MIL-PRF-39009RER45 Axial Box Chassis Mount Resistor ±1% ±50ppm/C 9.09Ohms 10W
PDF
/
Inventory: 5386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case Axial, Box
Mounting Feature Flanges
Housing Material Aluminium
Weight 8.8g
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Published 2013
Series Military, MIL-PRF-39009, RER45
Size / Dimension 0.750Lx0.800W 19.05mmx20.32mm
Tolerance ±1%
Feature Military, Moisture Resistant, Non-Inductive
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient ±50ppm/°C
Resistance 9.09Ohms
Max Operating Temperature 250°C
Min Operating Temperature -55°C
Composition Wirewound
Power (Watts) 10W
Power Rating 10W
Max Power Dissipation 10W
Military Standard MIL-PRF-39009
Failure Rate R (0.01%)
Lead Style Solder Lugs
Lead/Base Style Solder
Coating, Housing Type Aluminum
Dimensions
Height 10.287mm
Height Seated (Max) 0.405 10.29mm
Length 19.05mm
Width 20.32mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
