RER45F84R5PC02
RoHS
/
Package Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Military MIL-PRF-39009RER45 Axial Box Chassis Mount Resistor ±1% ±20ppm/C 84.5Ohms 10W
PDF
/
Inventory: 4740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 20.32mm
Length 34.93mm
Height Seated (Max) 0.405 10.29mm
Height 10.287mm
Technical
Coating, Housing Type Aluminum
Lead/Base Style Solder
Lead Style Solder Lugs
Failure Rate P (0.1%)
Military Standard MIL-PRF-39009
Depth 20.32mm
Max Power Dissipation 10W
Power Rating 10W
Power (Watts) 10W
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 250°C
Resistance 84.5Ohms
Temperature Coefficient ±20ppm/°C
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Military, Moisture Resistant, Non-Inductive
Tolerance ±1%
Size / Dimension 0.750Lx0.800W 19.05mmx20.32mm
Series Military, MIL-PRF-39009, RER45
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Weight 8.8g
Housing Material Aluminium
Mounting Feature Flanges
Package / Case Axial, Box
