NKAL50FB20R0
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
RES CHAS MNT 20 OHM 1% 50W
PDF
/
Inventory: 2323
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.641 16.28mm
Height 16.3068mm
Technical
Coating, Housing Type Aluminum
Lead/Base Style Solder
Lead Style Solder Lugs
Resistor Type FIXED RESISTOR
Construction Rectangular
Max Power Dissipation 50W
Composition Wirewound
Terminal Finish Matte Tin (Sn)
Resistance 20Ohm
Temperature Coefficient ±30ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Moisture Resistant, Non-Inductive
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 1.969Lx1.142W 50.00mmx29.00mm
Series KAL
Published 2010
Packaging Bulk
Operating Temperature -55°C~275°C
Physical
Housing Material Aluminium
Mounting Feature Flanges
Terminal Shape LUG
Surface Mount NO
Package / Case Axial, Box
Supply Chain
Factory Lead Time 14 Weeks
