SH2-100R0010DE

Ohmite
RoHS
RoHS RoHS compliant
Package Rectangular Case
Category Resistors / Chassis Mount Resistors
Description RES CHAS MNT 0.001 OHM 0.5% 10W
PDF
/
Buying Options
Total Price: USD $129.17
Unit Price: USD $129.1664
≥1 USD $129.1664
Inventory: 40
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Package / Case Rectangular Case
Mounting Feature Flanges
Housing Material Aluminium

Technical

Operating Temperature -55°C~110°C
Packaging Bulk
Published 2010
Series SH
Size / Dimension 6.496Lx2.362W 165.00mmx60.00mm
Tolerance ±0.5%
JESD-609 Code e3
Feature Current Sense, Moisture Resistant
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Temperature Coefficient 30ppm/°C
Resistance 1mOhm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Composition Metal Clad
Voltage - Rated 100mV
Subcategory Fixed Resistors
Power Rating 10W
Max Power Dissipation 10W
Technology METAL FILM
Resistor Type FIXED RESISTOR
Lead Style 4-Terminal
Coating, Housing Type Aluminum

Dimensions

Height 30.5054mm
Height Seated (Max) 1.220 31.00mm

Compliance

RoHS Status ROHS3 Compliant
