L50J75R
RoHS
/
Package Radial, Tubular
Category Resistors / Chassis Mount Resistors
Description
RES CHAS MNT 75 OHM 5% 50W
PDF
/
Buying Options
Total Price: USD $7.88
Unit Price: USD $7.8848
≥1 USD $7.8848
Inventory: 82
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Diameter - Inside 7.95 mm
Diameter 14.3mm
Technical
Load Current 816mA
Coating, Housing Type Vitreous Enamel Coated
Lead/Base Style Solder
Lead Style Solder Lugs
Resistor Type FIXED RESISTOR
Construction All-Welded
Depth 14.3mm
Technology WIRE WOUND
Max Power Dissipation 50W
Voltage - Rated DC 1kV
Power Rating 50W
Subcategory Fixed Resistors
Additional Feature FLAMEPROOF
Voltage - Rated 1.625kV
Composition Wirewound
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 75Ohm
Temperature Coefficient ±260ppm/°C
ECCN Code EAR99
Termination Lug
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Flame Retardant Coating, Safety
JESD-609 Code e0
Tolerance ±5%
Size / Dimension 0.563Diax4.000L 14.30mmx101.60mm
Series 270
Published 2014
Packaging Bulk
Operating Temperature -55°C~350°C
Physical
Housing Material Vitreous Enamel Coated
Mounting Feature Brackets (not included)
Terminal Shape LUG
Package / Case Radial, Tubular
Mount Bolt
Supply Chain
Factory Lead Time 10 Weeks
