F55J1K0
RoHS
/
Package Radial, Flat Oval
Category Resistors / Chassis Mount Resistors
Description
Wirewound Resistors 55watt 1K 5% High Power
PDF
/
Inventory: 7172
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 0.563 14.29mm
Height 14.3002mm
Technical
Coating, Housing Type Vitreous Enamel Coated
Lead/Base Style Solder
Lead Style Solder Lugs
Depth 25.4mm
Max Power Dissipation 55W
Power Rating 55W
Voltage - Rated 1.405kV
Composition Wirewound
Resistance 1kOhm
Temperature Coefficient ±260ppm/°C
Termination Lug
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Tolerance ±5%
Size / Dimension 3.500Lx1.000W 88.90mmx25.40mm
Series Stackohm? 250
Published 2008
Packaging Bulk
Operating Temperature -55°C~350°C
Physical
Housing Material Vitreous Enamel Coated
Mounting Feature Flange Braces, Right Angle
Package / Case Radial, Flat Oval
Mount Bolt
Supply Chain
Factory Lead Time 10 Weeks
