850FR70E
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Wirewound Resistors 50watt .7ohm 1%
PDF
/
Buying Options
Total Price: USD $9.83
Unit Price: USD $9.831114
≥1 USD $9.831114
≥10 USD $9.274643
≥100 USD $8.74966
≥500 USD $8.25439
≥1000 USD $7.787168
Inventory: 1170
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Package / Case Axial, Box
Surface Mount NO
Terminal Shape LUG
Mounting Feature Flanges
Housing Material Aluminium
Technical
Operating Temperature -55°C~275°C
Packaging Bulk
Published 2006
Series Metal-Mite?89
Size / Dimension 1.938Lx1.156W 49.23mmx29.36mm
Tolerance ±1%
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Temperature Coefficient ±90ppm/°C
Resistance 700mOhm
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Composition Wirewound
Voltage - Rated 1.17kV
Additional Feature POWER DISSIPATED USING HEAT SINK
Subcategory FIXED RESISTOR
Power Rating 50W
Max Power Dissipation 50W
Technology WIRE WOUND
Construction Molded
Resistor Type FIXED RESISTOR
Lead Length 11.13mm
Lead Style Solder Lugs
Lead/Base Style Solder
Coating, Housing Type Aluminum
Dimensions
Diameter 39.67mm
Height 16.6624mm
Height Seated (Max) 0.620 15.75mm
Compliance
RoHS Status ROHS3 Compliant
