825F15KE
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
Metal-Mite?89 FIXED RESISTOR Axial Box Chassis Mount Resistor ±1% ±20ppm/C 15kOhm 25W
PDF
/
Buying Options
Total Price: USD $8.31
Unit Price: USD $8.312607
≥1 USD $8.312607
≥10 USD $7.842086
≥100 USD $7.398189
≥500 USD $6.979431
≥1000 USD $6.584371
Inventory: 4822
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.556 14.12mm
Height 14.28mm
Diameter 18.26mm
Technical
Coating, Housing Type Aluminum
Lead/Base Style Solder
Lead Style Solder Lugs
Lead Length 11.13mm
Resistor Type FIXED RESISTOR
Construction Molded
Depth 27.79mm
Technology WIRE WOUND
Max Power Dissipation 25W
Power Rating 25W
Subcategory FIXED RESISTOR
Additional Feature POWER DISSIPATED USING HEAT SINK
Voltage - Rated 520V
Composition Wirewound
Resistance 15kOhm
Temperature Coefficient ±20ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±1%
Size / Dimension 1.062Lx1.094W 26.98mmx27.79mm
Series Metal-Mite?89
Published 2006
Packaging Tray
Operating Temperature -55°C~275°C
Physical
Housing Material Aluminium
Mounting Feature Flanges
Terminal Shape LUG
Surface Mount NO
Package / Case Axial, Box
Supply Chain
Factory Lead Time 26 Weeks
